Anatomy
Input allows developers to specify a set of configurations that merchants can adjust to customize a component. Each setting provides a specific control, from simple text inputs to complex selectors.
Input settings are generally composed of standard attributes. We can classify them into two main categories:
Overview
A quick look at an input
configs type:
type Input = { type: InputType name: string label?: string configs?: ConfigsType condition?: string defaultValue?: | string | number | boolean | Partial<WeaverseImage> | { [x: string]: any } placeholder?: string helpText?: string shouldRevalidate?: boolean}
Attributes Details
Here's a breakdown of the available attributes in an input setting:
Attribute | Type | Description | Required |
---|---|---|---|
type | InputType | Specifies the kind of UI control the merchant will interact with. | ✅ |
name | string | The key of the value in the component's data. E.g., "title" binds to component.data.title . | ✅ |
defaultValue | string | number | boolean | WeaverseImage | Sets initial values for inputs and initial data for the component. | ➖ |
label | string | A label for the input to show in the Weaverse Studio's Inspector | ➖ |
placeholder | string | A placeholder text to show when the input is empty. | ➖ |
configs | AdditionalInputConfigs | Additional options for inputs require more configuration. (Available for select , toggle-group , and range input) | ➖ |
condition | string | Only displays the input if the specified condition matches. | ➖ |
helpText | string | Provides additional information or instructions for the input setting (HTML format supported). | ➖ |
shouldRevalidate | boolean | Automatically revalidate the page when the input changes to apply new data from loader function. | ➖ |
-
condition
The
condition
attribute enables developers to define conditions under which an input will be displayed. It supports the following operators: -
eq
: equals -
ne
: not equals -
gt
: greater than -
gte
: greater than or equal to -
lt
: less than -
lte
: less than or equal toThe format is as follows:
bindingName.conditionalOperator.value
.Examples:
-
clickAction.eq.openLink
- Displays the input if theclickAction
is set toopenLink
. -
imagesPerRow.gt.1
- Displays the input if the number ofimagesPerRow
is greater than 1.
-
-
helpText
The
helpText
attribute can utilize HTML, offering more expressive help instructions. This allows for the inclusion of links, emphasis using bold or italics, lists, and more.Example:
Learn more about<a href="https://developer.mozilla.org/en-US/docs/Web/API/HTMLImageElement/loading" target="_blank" rel="noopener noreferrer" >image loading strategies</a>.
Will appear as:
Basic Inputs
text
The text input allows merchants to enter a single line of plain text. It's frequently used for capturing headings, button text, or short promotional messages.
Return: string
- The inputted text value.
Example:
{ type: "text", label: "Heading", name: "heading", defaultValue: "Testimonials", placeholder: "Enter section heading",}
Output:
![text_attribute_example](https://downloads.intercomcdn.com/i/o/853523424/b36bfc7fe1d4cc5e95953423/image.png)
textarea
The textarea input provides a multi-line text box suitable for longer descriptions, like testimonials, user reviews, or shipping and return policies.
Return: string
- The inputted multiline text value.
Example:
{ type: "textarea", label: "Customer testimonial", name: "customerTestimonial", defaultValue: "The shipping was fast, and the packaging was eco-friendly. I love shopping here!", placeholder: "Share customer shopping experience..."}
Output:
![textarea_attribute_example](https://downloads.intercomcdn.com/i/o/853526819/4cd07fba93f159e18ec1c671/image.png)
switch
The switch input provides a toggle option. This can be useful for enabling or disabling product availability, promotional features, or customer reviews.
Return: boolean
- Indicates whether the switch is turned on (true
) or off (false
).
Example:
{ type: "switch", label: "Enable discount", name: "enableDiscount", defaultValue: true,}
Output:
![switch_attribute_example](https://downloads.intercomcdn.com/i/o/853527375/2de182c3854357176a717e51/image.png)
range
The range input lets merchants select a value within a set range. This can be used for adjusting quantities, setting percentages, or customizing display sizes.
Return: number
- The selected value within the defined range.
Example:
{ type: "range", label: "Discount percentage", name: "discountPercentage", defaultValue: 10, configs: { min: 5, max: 50, step: 1, unit: "%" }}
Output:
![range_attr_example](https://downloads.intercomcdn.com/i/o/853529726/f21af857ecba39099bd8fca6/image.png)
configs
details:
Property | Type | Description | Required |
---|---|---|---|
min | number | The minimum value the range input can have. | ✅ |
max | number | The maximum value the range input can have. | ✅ |
step | number | The intervals between values in the range. | ✅ |
unit | string | A unit of measure displayed next to the value (e.g., px , % ). Purely for display purposes. | ➖ |
select
The select input provides a dropdown list, allowing merchants to select one option from a predefined list of options.
Return: string
- The selected option's value.
Example:
{ type: "select", label: "Image aspect ratio", name: "imageAspectRatio", configs: { options: [ { value: "auto", label: "Adapt to image" }, { value: "1/1", label: "1/1" }, { value: "3/4", label: "3/4" }, { value: "4/3", label: "4/3" }, ] }, defaultValue: "auto"}
Output:
![aspect_ratio_select_0](https://downloads.intercomcdn.com/i/o/853536003/389c8a3340b9dba42c539e73/image.png)
![aspect_ratio_select_1](https://downloads.intercomcdn.com/i/o/853536156/7ff5f0a96a77d7ef2b48f7c3/image.png)
configs
details:
Property | Type | Description | Required |
---|---|---|---|
options | Array<OptionType> | An array containing all options. Each option must be an object. | ✅ |
↳ value | string | A unique value for the option. | ✅ |
↳ label | string | Displayed text for the option. | ✅ |
toggle-group
The toggle group input allows merchants to make a selection from a group of toggleable options (only one choice is allowed).
While it functions similarly to the select
input, its UI is distinct, showcasing options as toggle buttons. This
makes it particularly useful and user-friendly for cases with fewer options, allowing for a more intuitive selection
process.
Return: string
- The chosen option's value.
Example (Display as Text):
{ type: "select", label: "Image aspect ratio", name: "imageAspectRatio", configs: { options: [ { value: "auto", label: "Adapt to image" }, { value: "1/1", label: "1/1" }, { value: "3/4", label: "3/4" }, { value: "4/3", label: "4/3" }, ] }, defaultValue: "auto"}
Output:
![display_as_text](https://downloads.intercomcdn.com/i/o/853548031/e61ae5709eba893c8f58e375/image.png)
Example (Display as Icon):
{ type: "toggle-group", name: "loading", label: "Background image loading", configs: { options: [ {label: "Eager", value: "eager", icon: "Lightning"}, {label: "Lazy", value: "lazy", icon: "SpinnerGap"}, ], }, defaultValue: "eager", helpText: 'Learn more about <a href="https://developer.mozilla.org/en-US/docs/Web/API/HTMLImageElement/loading" target="_blank" rel="noopener noreferrer">image loading strategies</a>.',}
Output:
![display_as_icon](https://downloads.intercomcdn.com/i/o/853553481/2622731c03fb54b97d93cc50/image.png)
configs
details
Property | Type | Description | Required |
---|---|---|---|
options | Array<OptionType> | An array of OptionType objects. See below for the details of each property on an option. | ✅ |
↳ value | string | A unique value for the option. | ✅ |
↳ label | string | Displayed text for the option. | ✅ |
↳ icon | string | Displayed icon for the option. When an icon is set, the label will act as its tooltip . | ➖ |
↳ weight | string | An optional weight for the icon, which can be one of the following values: thin | light | regular | bold | fill | duotone | ➖ |
💡 Note for icons:
-
We use Lucide Icons library for the icons.
-
The value is the Icon name (e.g: mail-search, bar-chart-horizontal...)
-
Not all icons are supported yet. Please contact us if you need an icon that is missing from your configs.
richtext
The richtext
input allows merchants to craft content using a rich text editor, providing flexibility and more
advanced text formatting options.
Return: string
- A string containing rich-text (HTML) formatted content.
Example:
{ type: "richtext", label: "Promotion details", name: "promotionDetails", defaultValue: "<p>We're excited to announce our <strong>limited-time</strong> savings event. From <em>October 15th to November 15th</em>, enjoy exclusive discounts and offers.</p>"}
Output:
![richtext_output](https://downloads.intercomcdn.com/i/o/853955513/d0657f49a2d017ac0a01ecb1/image.png)
🌟 Pro Tip: our richtext
input comes with AI-powered content generation capabilities, allowing merchants to
effortlessly craft top-notch content, from descriptions to promotional texts and more.
![richtext_power_ai_output](https://downloads.intercomcdn.com/i/o/853957251/aed40de2d47ce9e232f6f5f0/image.png)
The image
input offers merchants the ability to select or upload images.
Here's how it works:
-
Media Manager: on open, it displays the Media Manager modal with all images from the Files page of the merchant's Shopify Admin.
-
Uploading Images: any image a merchant uploads through this input is saved to the Files page as well.
-
Enhancing SEO: merchants can edit the alt text of the images they've uploaded.
Return: object
- A WeaverseImage
(type can be imported from @weaverse/hydrogen
package).
WeaverseImage
type definition:
type WeaverseImage = { id: string url: string altText: string width: number height: number}
Example:
{ type: "image", name: "authorImage", label: "Author image", defaultValue: { url: "https://cdn.shopify.com/s/files/1/0669/0262/2504/files/linkedin-sales-solutions-pAtA8xe_iVM-unsplash.jpg?v=1697429747", altText: "Man standing beside wall", width: 689, height: 1034, }, /* The following `defaultValue` are acceptable as well: defaultValue: { url: "https://cdn.shopify.com/s/files/1/0669/0262/2504/files/linkedin-sales-solutions-pAtA8xe_iVM-unsplash.jpg?v=1697429747", }, defaultValue: "https://cdn.shopify.com/s/files/1/0669/0262/2504/files/linkedin-sales-solutions-pAtA8xe_iVM-unsplash.jpg?v=1697429747", */}
📌 Note: The defaultValue
in the input configuration can either be:
-
an object of the
WeaverseImage
type (where all properties are optional except for theurl
) -
or a
string
representing the image URL
Output:
![image_attr](https://downloads.intercomcdn.com/i/o/854078553/0287d7d2d96404caf442954a/image.png)
Usage
We highly recommend developers to utilize the Image
component from the @shopify/hydrogen
package to render images. It's optimized to work with the data returned from
the image
input, ensuring efficient image delivery.
Here's a simple example:
import { Image } from '@shopify/hydrogen'import type { HydrogenComponentProps, WeaverseImage } from '@weaverse/hydrogen'import { forwardRef } from 'react'
interface ImageGalleryItemProps extends HydrogenComponentProps { source: WeaverseImage}
let ImageGalleryItem = forwardRef<HTMLImageElement, ImageGalleryItemProps>( (props, ref) => { let { source, ...rest } = props /* Pass the object returned from the `image` input (name it as you like, e.g., `source`) directly to the `data` prop of the `Image` component. This will automatically generate all the necessary attributes for the image element. */ return ( <Image ref={ref} {...rest} data={source} sizes={`(min-width: 45em) 50vw, 100vw`} /> ) },)
export default ImageGalleryItem
video
The video
input offers merchants the ability to select or upload videos.
Here's how it works:
-
Media Manager: on open, it displays the Media Manager modal with all videos from the Files page of the merchant's Shopify Admin.
-
Uploading Videos: any video a merchant uploads through this input is saved to the Files page as well.
-
Enhancing SEO: merchants can edit the alt text of the videos they've uploaded.
Return: object
- A WeaverseVideo
(type can be imported from @weaverse/hydrogen
package).
WeaverseVideo
type definition:
type WeaverseVideo = { id: string url: string altText: string width: number height: number previewSrc: string}
Example:
{ type: "video", name: "video", label: "Video",},
Output:
![image_attr](https://cdn.shopify.com/s/files/1/0838/0052/3057/files/weaverse_video_input.png?v=1722415681)
color
The color
input type allows merchants to select a color using a color picker. This can be handy for design-related
settings, such as background color, text color, border color, etc.
Return: string
- A color in hex
format (e.g., #RRGGBB
or #RRGGBBAA
if alpha is set).
Example:
{ type: "color", label: "Background color", name: "backgroundColor", defaultValue: "#FFFFFF",}
Output:
![color_attr](https://downloads.intercomcdn.com/i/o/854847973/ec48b59238cd31ccd212ee09/image.png)
datepicker
The datepicker
input type provides merchants with a way to select a specific date and time, making it ideal for
scheduling content, setting event dates, or determining promotional periods.
Return: number
- A timestamp of the selected date and time.
Example:
{ type: "datepicker", label: "Start date", name: "startDate", defaultValue: "2024-01-01"}
Output:
![datapicker_attr](https://downloads.intercomcdn.com/i/o/855105562/73bcbd974a3b74d986450806/image.png)
💡 Parsing: The returned timestamp should be transformed into a readable date-time string, for example:
// Get the `timestamp` from Weaverse Component propslet timestamp = 1704067200000let date = new Date(timestamp)
// Parsing examples:console.log(date.toISOString().split('T')[0]) // => "2024-01-01"console.log( date.toLocaleDateString('en-US', { month: 'long', day: 'numeric', year: 'numeric', }),) // => "January 1, 2024"
map-autocomplete
🚧 - Experimental feature, may not work as expected.
The map-autocomplete
input provides merchants with a location-based autocomplete functionality. As merchants type in
the input, a dropdown list of suggested places appears.
Return: string
- The selected location or place name from the dropdown suggestions.
Example:
{ type: "map-autocomplete", name: "address", label: "Business address", defaultValue: "San Francisco, CA"}
Output:
![map_autocomplete_attr](https://downloads.intercomcdn.com/i/o/855138136/aca08efac8fecde1f5d74fa8/image.png)
position
The position
input enables merchants to select a content alignment from a predefined subset of positions using
intuitive directional arrows.
Return: string
- The selected content position from the available choices.
The position can be one of the following
values: top left
| top center
| top right
| center left
| center center
| center right
| bottom left
| bottom center
| bottom right
Example:
{ type: "position", name: "contentPosition", label: "Content position", defaultValue: "center center"}
Output:
![position_attr](https://cdn.shopify.com/s/files/1/0838/0052/3057/files/weaverse_position_input.png?v=1722416367)
Resource Picker Inputs
url
The url
input allows merchants to enter a URL or select a page from their store using the internal link picker.
Return: string
- The entered URL or the selected page's URL.
Example:
{ type: "url", label: "Button link", name: "buttonLink", defaultValue: "/products"}
Output:
![product_attr](https://cdn.shopify.com/s/files/1/0838/0052/3057/files/url_input.png?v=1712823900)
product
The product
input provides merchants with an intuitive search and select interface to choose a specific product
from their store.
Return: object
- A WeaverseProduct
object (type can be imported from @weaverse/hydrogen
package).
WeaverseProduct
type definition:
type WeaverseProduct = { id: number handle: string}
Example:
{ type: "product", name: "product", label: "Featured product",}
Output:
![product_attr](https://downloads.intercomcdn.com/i/o/856020670/e25984f0879ed95300da690b/image.png)
When selecting a product, the preview will automatically revalidate and run the loader
function.
The loader
function will read the handle
or id
of the selected product and fetch all the product data from the Storefront API. Here's an example of how to use the loader
function:
// <root>/app/sections/single-product/index.tsx
export let loader = async (args: ComponentLoaderArgs<SingleProductData>) => { let { weaverse, data } = args let { storefront } = weaverse if (!data?.product) { return null } let productHandle = data.product.handle let { product, shop } = await storefront.query<ProductQuery>(PRODUCT_QUERY, { variables: { handle: productHandle, selectedOptions: [], language: storefront.i18n.language, country: storefront.i18n.country, }, }) let variants = await storefront.query(VARIANTS_QUERY, { variables: { handle: productHandle, language: storefront.i18n.language, country: storefront.i18n.country, }, })
return { product, variants, storeDomain: shop.primaryDomain.url, }}
product-list
The product-list
input provides merchants with an intuitive search and select interface to choose multiple products
from their store.
Return: array
- An array of WeaverseProduct
object with their respective IDs and handles.
Example:
{ label: "Select products", name: "products", type: "product-list",}
Output:
![product_list_attr](https://downloads.intercomcdn.com/i/o/856048741/4a8bed2630a0f1f454047e80/image.png)
Similar to the product
input, the preview will automatically revalidate and run the loader
function when selecting products. Please use the handle
or id
of the selected product to fetch the full product data.
collection
The collection
input provides merchants with an intuitive search and select interface to choose a specific collection
from their store.
Return: object
- A WeaverseCollection
object (type can be imported from @weaverse/hydrogen
package).
Example:
{ type: "collection", name: "collection", label: "Collection",}
Output:
![collection_attr](https://downloads.intercomcdn.com/i/o/856069172/ee5a9e5e663fc816ac837127/image.png)
Similar to the product
input, the preview will automatically revalidate and run the loader
function when selecting a collection. Please use the handle
or id
of the selected collection to fetch the full collection data.
collection-list
The collection-list
input provides merchants with an intuitive search and select interface to choose multiple
collections from their store.
Return: array
- An array of WeaverseCollection
object with their respective IDs and handles.
Example:
{ type: "collection-list", name: "collections", label: "Select collections",}
Output:
![collection_list_attr](https://downloads.intercomcdn.com/i/o/856071108/d3baad59f89283e788ce04cc/image.png)
Similar to the product
input, the preview will automatically revalidate and run the loader
function when selecting collections. Please use the handle
or id
of the selected collection to fetch the full collection data.
blog
The blog
input provides merchants with an intuitive search and select interface to choose a specific blog from their
store.
Return: object
- A WeaverseBlog
object (type can be imported from @weaverse/hydrogen
package).
Example:
{ type: "blog", name: "blog", label: "Blog",}
Output:
![blog_attr](https://downloads.intercomcdn.com/i/o/856089471/83cf34f9ba89fa9043db3293/image.png)
Similar to the product
input, the preview will automatically revalidate and run the loader
function when selecting a blog. Please use the handle
or id
of the selected blog to fetch the full blog data.
metaobject
The metaobject
input provides merchants with an intuitive search and select interface to choose a specific metaobject definition from their store.
Return: object
- A WeaverseMetaobject
(type can be imported from @weaverse/hydrogen
package).
Example:
{ label: "Select metaobject definition", type: "metaobject", name: "ourTeam"}
Output:
![metaobject_attr](https://cdn.shopify.com/s/files/1/0838/0052/3057/files/weaverse_metaobject_input.png?v=1722477096)
When selecting a metaobject definition, the preview will automatically revalidate and run the loader
function.
The loader
function will read the type
of the selected metaobject definition and fetch all the metaobject data from the Storefront API. Here's an example of how to use the loader
function:
import type { ComponentLoaderArgs, WeaverseMetaObject } from '@weaverse/hydrogen'
type OurTeamData = { metaobject: WeaverseMetaObject; membersCount: number;};
export let loader = async (args: ComponentLoaderArgs<OurTeamData>) => { let { weaverse, data } = args; let { storefront } = weaverse; let { metaobject, membersCount } = data; if (metaobject) { return await storefront.query<OurTeamQuery>(OUR_TEAM_QUERY, { variables: { type: metaobject.handle, first: membersCount, }, }); } return null;};
Querying Storefront Data
After using the Resource Picker inputs, you might notice that the returned data is limited, typically just the id
and handle
of the selected resource. In most cases, you'll need more detailed data for your components or routes.
This is where the Weaverse client comes in handy. Using its storefront.query
function, you can fetch the full
set of data related to your selection from Shopify's Storefront API.
To learn more about how to effectively fetch and utilize data within Weaverse, refer to our dedicated section on Data Fetching & Caching.
Next Steps
Now that you have a solid understanding of Input Settings, let's learn how to render a Weaverse page in the next article: Rendering a Weaverse Page.
